Products
IMAC Resin
Product Introduction

Metal Chelation Affinity Chromatography, also known as Immobilized Metal Ion Affinity Chromatography (IMAC), utilizes specific interactions between amino acid residues (histidine, tryptophan, cysteine) on protein surfaces and metal ions (Ni²⁺, Cu²⁺, Zn²⁺, Co²⁺, Ca²⁺, Fe³⁺) for protein purification.

IMAC Singarose FF/HP are metal chelation affinity resins prepared by coupling nitrilotriacetic acid (NTA) ligands to a 6% highly cross-linked agarose matrix. These resins provide four coordination sites for stable metal ion chelation (Ni²⁺/Cu²⁺/Zn²⁺/Co²⁺) and exhibit excellent tolerance to reducing agents. After user-specific metal ion loading, they are suitable for downstream purification of proteins/peptides in biopharmaceuticals and bioengineering applications.

Product Highlights
Stably Chelated Metal Ions, Low Ligand Leakage
Excellent Stability, Good Reproducibility
Single-Step Purification, High Resolution, High Binding Capacity
High Selectivity, Tolerant to Certain Concentrations of Reducing Agents
Strong Hydrophilicity, Minimal Non-specific Adsorption, Easy Process Scale-Up
Technical Parameters
Product Name IMAC Singarose FF IMAC Singarose HP
Matrix 6% Highly Cross-linked Agarose Resin
Average Particle Size 90 µm 34 µm
Functional Ligand Nitrilotriacetic Acid (NTA)
Metal Chelation Capacity 15 µmol Ni²⁺/mL Resin
Binding Capacity ~40 mg Histidine-tagged Protein/mL Resin (Ni²⁺-loaded)
Recommended Flow Rate <400 cm/h <150 cm/h
Recommended Pressure <0.3 MPa (3 bar)
Operating pH Range 4-8.5
pH Stability 3-12 (Long-term*); 2-14 (Short-term*)
Chemical Compatibility Stable in common buffers; avoid chelating agents (e.g., EDTA, citrate)
Storage Conditions 20% Ethanol; 4-30℃

Note *: Long-term refers to resin stability without performance degradation. Short-term refers to pH ranges experienced during regeneration, CIP, and sanitization. This note applies to unchelated resin.

Ordering Information
Product Name Catalog No. Specification
IMAC Singarose FF HC1040101 25 mL
HC1040102 100 mL
HC1040104 1 L
HC1040105 5 L
IMAC Singarose HP HC1040001 25 mL
HC1040002 100 mL
HC1040004 1 L
HC1040005 5 L
